Tektronix DPO70000C/DX Series User Manual

Bus setups Select the SPI bus framing
Select the SPI bus framing
NOTE. The SPI bus Framing option is available only on instruments with option SR-EMBD.
From the Bus Setup window, select the Select tab and the SPI Serial bus type.
To use
Select the framing from the drop-down list.
Select SS framing for three wire SPI decode.
Select Idle framing for two wire SPI decode.
Behavi
or
The instrument changes the framing and uses that to decode t he selected SPI bus.
What do you want to do next?
Learn more about b us setups. (see page 95)
Learn a bout bus configuration. (see page 148)
Learn about digital setups. (see page 87)
136 DSA/DPO70000D, MSO/DPO/DSA70000C, DPO7000C, and MSO/DPO5000 Series

Tektronix DPO70000C/DX Series Specifications

General

Vertical Sensitivity	1 mV/div to 1 V/div
Input Coupling	AC, DC, GND
Interface	USB, LAN, GPIB, HDMI
Power Requirements	100-240 VAC, 50/60 Hz
Channels	4
Display	12.1-inch LCD
Input Impedance	50 Ω or 1 MΩ
Trigger Types	Edge, Pulse Width, Runt, Window, Logic, Setup/Hold, Rise/Fall Time, Video, Serial
Vertical Resolution	up to 12 bits
Operating Temperature	0°C to +50°C
Sample Rate	up to 100 GS/s
