Analyzing waveforms Set up MIL-1553 search parameters

Search for end of frame

Search for error

Set up M IL-1553 search parameters

After setting up a MIL-1553 bus, go to the Analyze menu, select Search, and then select the Bus trigger

type; then open the Conﬁgure tab.

Overview

Use the controls to set up the MIL-1553 Bus parameters.

To use

For information o n the controls, click the buttons.

DSA/DPO70000D, MSO/DPO/DSA70000C, DPO7000C, and MSO/DPO5000 Series 357
