Oscilloscope Reference Width trigger
Width trigger
A width trigger occurs when the instrument detects a pulse that is inside or outside s ome specified time
range. The instrument c an trigger on positive or negative width pulses. Width triggers can also be qualified
by the logica
l state of other channels.
Window trigger
NOTE. Wind
ow trigger is not available on MSO/DPO5000 Series instruments.
Use the Window trigger to trigger the instrument when the input signal rises above an upper threshold
level or f
alls below a lower threshold level.
After setting these levels, you can specify whether you want to trigger the instrument as the signal is
enterin
g or leaving the threshold window. You can further qualify the trigger event in terms of time, or
by the logical state of other channels.
710 DSA/DPO70000D, MSO/DPO/DSA70000C, DPO7000C, and MSO/DPO5000 Series
