Bus setups Select the RS-232 bus data b its

Select the RS-232 bus data bits

NOTE. The RS-232 Bus Data Bits option is a vailable only on instruments with option S R-COMP.

From the Bus Setup window, select the Select tab and the RS-232 Serial bus type.

To use

Scroll through the Bus list and select the RS-232 bus to conﬁgure.

Click the Data Bits box and select the data bits from the drop-down list.

Behavior

You have the option to set the number of data bits in a frame for RS-232 bus to:

8, the default.

What do you want to do next?

Learn more about bus setups. (see page 95)

Learn about bus conﬁguration. (see page 148)

Learn about digital setups. (see page 87)
