Analyzing waveforms View the protocol decode e vent table
To use
To view the decoded contents of a bus, select the tab for the bus. There is one tab for each defined bus.
Behavior
This dialog box opens when you click Protocol Event Table from the Bus Setup Display tab, or in the
Analyze menu, when you sele ct Protocol Decode Event Table.
Symbol substitution, annotation and radix behavior is controlled by the Bus Setup control window. There
is one row per bus packet. There is one column per visible property or nondetail field in the bus. You can
change the
column width and column order. Some rows can be expanded to show field details.
Two types of icons are displayed in the Index column.
An Error/Warning icon is displayed if the packet contains an error or warning.
If the packet contains collapsed detail, the Expand icon is displayed. Click on the icon to expand the
packet detail. If the packet detail is expanded, the Collapse icon is displayed. Click on the icon to close the
expan
ded detail.
Event Table data and Waveform Zoom 1 are correlated with each other. Event Table highlights rows
th
at intersect with the current Waveform Zoom 1, if enabled. Waveform Zoom 1 moves zoom to center
around the selected row in the event table.
Dock or undock the event table
To dock or undock the event table to the graticule, press the Dock button.
DSA/DPO70000D, MSO/DPO/DSA70000C, DPO7000C, and MSO/DPO5000 Series 371
