Yamaha 2014 MT-07 Service Manual

GENERAL CHASSIS (2)
4-3
EAS20155
GENERAL CHASSIS (2)
Removing the covers, tail/brake light assembly, and mudguard
Order Job/Parts to remove Q’ty Remarks
Rider seat/passenger seat
Refer to “GENERAL CHASSIS (1)” on page
4-1.
1 Center cover 1
2 Upper tail cover 1
3Lower tail cover 1
4 Rear side cover (left) 1
5 Rear side cover (right) 1
6 Lining cover (left) 1
7 Lining cover (right) 1
8 Tail/brake light coupler 1 Disconnect.
2
(4)
3
1
5
7
8
LT
4
6
10 Nm (1.0 m
•
kgf, 7.2 ft
•
Ibf)
T
.
R
.
1.5 Nm (0.15 m
•
kgf, 1.1 ft
•
Ibf)
T
.R.
1.5 Nm (0.15 m
•
kgf, 1.1 ft
•
Ibf)
T
.R
.
3.3 Nm (0.33 m
•
kgf, 2.4 ft
•
Ibf)
T
.
R
.
7 Nm (0.7 m
•
kgf, 5.1 ft
•
Ibf)
T
.R
.
7 Nm (0.7 m
•
kgf, 5.1 ft
•
Ibf)
T
.
R.
16 Nm (1.6 m
•
kgf, 12 ft
•
Ibf)
T
.
R
.
16 Nm (1.6 m
•
kgf, 12 ft
•
Ibf)
T
.
R.
