Yamaha 2014 MT-07 Service Manual

FRONT BRAKE
4-35
EAS20030
FRONT BRAKE
Removing the front brake pads
Order Job/Parts to remove Q’ty Remarks
The following procedure applies to both of
the front brake calipers.
1 Brake pad clip 2
2 Brake pad pin 1
3 Brake pad spring 1
4Brake pad 2
5 Front wheel sensor lead holder 2 Right side only.
6 Front brake caliper 1
7 Brake caliper bleed screw 1 Left side only.
8 Brake caliper bleed screw 1 Right side only.
3
6
4
2
7
8
1
5
New
4
LS
40 Nm (4.0 m
•
kgf, 29 ft
•
Ibf)
T
.R.
5 Nm (0.5 m
•
kgf, 3.6 ft
•
Ibf)
T
.R.
5 Nm (0.5 m
•
kgf, 3.6 ft
•
Ibf)
T
.R
.

Yamaha 2014 MT-07 Specifications

General

Engine Type	Liquid-cooled, 4-stroke, DOHC, 4-valve
Displacement	689 cc
Bore x Stroke	80.0 mm x 68.6 mm
Compression Ratio	11.5:1
Maximum Torque	68.0 Nm (6.9 kg-m) @ 6, 500 rpm
Fuel System	Fuel Injection
Ignition System	TCI
Transmission	Constant Mesh, 6-speed
Final Drive	Chain
Front Suspension	Telescopic forks
Front Brake	Hydraulic dual disc, Ø 282 mm
Rear Brake	Hydraulic single disc, Ø 245 mm
Front Tyre	120/70 ZR17M/C (58W)
Rear Tyre	180/55 ZR17M/C (73W)
Dimensions (L x W x H)	2, 085 mm x 745 mm x 1, 090 mm
Seat Height	805 mm
Wheelbase	1, 400 mm
Minimum Ground Clearance	140 mm
Wet Weight	179 kg
Fuel Tank Capacity	14 L
Maximum Power	74.8 PS (55.0 kW) @ 9, 000 rpm
Rear Suspension	Swingarm (Link type suspension)
