Yamaha 2014 MT-07 Service Manual

CYLINDER HEAD
5-25
EAS20044
CYLINDER HEAD
Removing the cylinder head
* Following the tightening order, loosen the bolt one by one, and then retighten it to the specific torque.
Order Job/Parts to remove Q’ty Remarks
Rider seat
Refer to “GENERAL CHASSIS (1)” on page
4-1.
Fuel tank top cover/Fuel tank side covers/Fuel
tank center cover/Fuel tank front cover
Refer to “GENERAL CHASSIS (4)” on page
4-11.
Fuel tank Refer to “FUEL TANK” on page 7-1.
Air duct bracket
Refer to “AIR FILTER CASE VALVE” on
page 7-6.
Throttle bodies Refer to “THROTTLE BODIES” on page 7-9.
Footrest assembly (right) Refer to “REAR BRAKE” on page 4-49.
10 Nm (1.0 m
•
kgf, 7.2 ft
•
Ibf)
T.R.
10 Nm (1.0 m
•
kgf, 7.2 ft
•
Ibf)
T.
R
.
16 Nm (1.6 m
•
kgf, 12 ft
•
Ibf)
T.R.
25 Nm (2.5 m
•
kgf, 18 ft
•
Ibf)
T
.
R.
25 Nm (2.5 m
•
kgf, 18 ft
•
Ibf)
T
.
R.
55 Nm (5.5 m
•
kgf, 40 ft
•
Ibf)
T.R.
55 Nm (5.5 m
•
kgf, 40 ft
•
Ibf)
T
.
R.
75 Nm (7.5 m
•
kgf, 54 ft
•
Ibf)
T
.
R.
75 Nm (7.5 m
•
kgf, 54 ft
•
Ibf)
T
.
R.
10 Nm (1.0 m
•
kgf, 7.2 ft
•
Ibf)
T
.
R.
10 Nm (1.0 m
•
kgf, 7.2 ft
•
Ibf)
20 Nm (2.0 m
•
kgf, 14 ft
•
Ibf)
40 Nm (4.0 m
•
kgf, 29 ft
•
Ibf)
1st
2nd
T
.
R.
3rd
Specified angle 90˚
*
LT
E
S
New
New
New
2
6
11
6
13
15
7
8
14
1
9
5
4
3
3
(6)
17
16
12
10

Yamaha 2014 MT-07 Specifications

General

Engine Type	Liquid-cooled, 4-stroke, DOHC, 4-valve
Displacement	689 cc
Bore x Stroke	80.0 mm x 68.6 mm
Compression Ratio	11.5:1
Maximum Torque	68.0 Nm (6.9 kg-m) @ 6, 500 rpm
Fuel System	Fuel Injection
Ignition System	TCI
Transmission	Constant Mesh, 6-speed
Final Drive	Chain
Front Suspension	Telescopic forks
Front Brake	Hydraulic dual disc, Ø 282 mm
Rear Brake	Hydraulic single disc, Ø 245 mm
Front Tyre	120/70 ZR17M/C (58W)
Rear Tyre	180/55 ZR17M/C (73W)
Dimensions (L x W x H)	2, 085 mm x 745 mm x 1, 090 mm
Seat Height	805 mm
Wheelbase	1, 400 mm
Minimum Ground Clearance	140 mm
Wet Weight	179 kg
Fuel Tank Capacity	14 L
Maximum Power	74.8 PS (55.0 kW) @ 9, 000 rpm
Rear Suspension	Swingarm (Link type suspension)
