CLUTCH
5-50
EAS20055
CLUTCH
Removing the clutch cover and pull lever shaft
Order Job/Parts to remove Q’ty Remarks
Engine oil
Drain.
Refer to “CHANGING THE ENGINE OIL” on
page 3-22.
Water pump housing Refer to “WATER PUMP” on page 6-9.
1 Clutch cable 1 Disconnect.
2 Clutch cable holder 1
3
Holder (O
2
sensor lead and oil pressure switch
lead)
2
4 Clutch cover 1
5 Clutch cover gasket 1
1
2
(8)
4
5
3
3
LS
New
New
E
E
LT
LT
12 Nm (1.2 m
•
kgf, 8.7 ft
•
Ibf)
T
.
R
.
12 Nm (1.2 m
•
kgf, 8.7 ft
•
Ibf)
T
.
R
.
7 Nm (0.7 m
•
kgf, 5.1 ft
•
Ibf)
T
.
R
.
To Next Page
