Yamaha 2014 MT-07 Service Manual

TIGHTENING TORQUES
2-20
EAS30017
CHASSIS TIGHTENING TORQUES
Item
Thread
size
Q’ty Tightening torque Remarks
Engine mounting nut (rear upper
side)
M10 1 55 Nm (5.5 m·kgf, 40 ft·lbf)
Engine mounting nut (rear lower
side)
M10 1 55 Nm (5.5 m·kgf, 40 ft·lbf)
Engine mounting bolt (left front side) M12 1 75 Nm (7.5 m·kgf, 54 ft·lbf)
Engine mounting bolt (left upper
side)
M10 1 55 Nm (5.5 m·kgf, 40 ft·lbf)
Engine mounting bolt (right front
side)
M12 1 75 Nm (7.5 m·kgf, 54 ft·lbf)
Engine mounting bolt (right upper
side)
M10 1 55 Nm (5.5 m·kgf, 40 ft·lbf)
Engine bracket bolt (right) M8 2 25 Nm (2.5 m·kgf, 18 ft·lbf)
Engine bracket bolt (left) M8 2 25 Nm (2.5 m·kgf, 18 ft·lbf)
Clutch cable guide bolt M6 1 7 Nm (0.7 m·kgf, 5.1 ft·lbf)
Rider seat bracket bolt M6 4 7 Nm (0.7 m·kgf, 5.1 ft·lbf)
Battery terminal bolt M6 2 2.2 Nm (0.22 m·kgf, 1.6 ft·lbf)
Rider seat bolt M6 2 7 Nm (0.7 m·kgf, 5.1 ft·lbf)
Lean angle sensor bolt M4 2 2.0 Nm (0.20 m·kgf, 1.4 ft·lbf)
Starter relay bolt M6 2 3.6 Nm (0.36 m·kgf, 2.6 ft·lbf)
Battery box bolt M6 2 7 Nm (0.7 m·kgf, 5.1 ft·lbf)
Rear side cover bolt (M8 × 25 mm) M8 2 16 Nm (1.6 m·kgf, 12 ft·lbf)
Rear side cover bolt (M6 × 12 mm) M6 2 7 Nm (0.7 m·kgf, 5.1 ft·lbf)
Tail/brake light bolt M6 2 3.3 Nm (0.33 m·kgf, 2.4 ft·lbf)
Mudguard assembly bolt M6 4 10 Nm (1.0 m·kgf, 7.2 ft·lbf)
License plate/turn signal light bolt M6 4 10 Nm (1.0 m·kgf, 7.2 ft·lbf)
Center cover screw M5 2 1.5 Nm (0.15 m·kgf, 1.1 ft·lbf)
Upper tail cover screw M5 2 1.5 Nm (0.15 m·kgf, 1.1 ft·lbf)
Headlight assembly bolt M6 2 7 Nm (0.7 m·kgf, 5.1 ft·lbf)
Headlight side cover bolt M6 2 7 Nm (0.7 m·kgf, 5.1 ft·lbf)
Headlight center cover bolt M6 4 0.8 Nm (0.08 m·kgf, 0.58 ft·lbf)
Meter assembly screw M4 3 1.3 Nm (0.13 m·kgf, 0.94 ft·lbf)
Meter assembly bracket bolt M6 2 7 Nm (0.7 m·kgf, 5.1 ft·lbf)
Fuel tank top cover bolt M5 1 1.5 Nm (0.15 m·kgf, 1.1 ft·lbf)
Fuel tank cover bolt (M5 × 12 mm) M5 2 1.5 Nm (0.15 m·kgf, 1.1 ft·lbf)
Fuel tank cover bolt (M5 × 16 mm) M5 8 1.5 Nm (0.15 m·kgf, 1.1 ft·lbf)
Fuel tank center cover bolt M5 2 1.5 Nm (0.15 m·kgf, 1.1 ft·lbf)
Air scoop bolt M6 4 7 Nm (0.7 m·kgf, 5.1 ft·lbf)
Fuel tank front cover lower bolt M6 2 4.0 Nm (0.40 m·kgf, 2.9 ft·lbf)
Fuel tank front cover upper bolt M5 2 2.5 Nm (0.25 m·kgf, 1.8 ft·lbf)
Air scoop inner panel bolt M5 6 1.5 Nm (0.15 m·kgf, 1.1 ft·lbf)
Electrical components tray 1 bolt M6 2 7 Nm (0.7 m·kgf, 5.1 ft·lbf)
LT

Yamaha 2014 MT-07 Specifications

General

Engine Type	Liquid-cooled, 4-stroke, DOHC, 4-valve
Displacement	689 cc
Bore x Stroke	80.0 mm x 68.6 mm
Compression Ratio	11.5:1
Maximum Torque	68.0 Nm (6.9 kg-m) @ 6, 500 rpm
Fuel System	Fuel Injection
Ignition System	TCI
Transmission	Constant Mesh, 6-speed
Final Drive	Chain
Front Suspension	Telescopic forks
Front Brake	Hydraulic dual disc, Ø 282 mm
Rear Brake	Hydraulic single disc, Ø 245 mm
Front Tyre	120/70 ZR17M/C (58W)
Rear Tyre	180/55 ZR17M/C (73W)
Dimensions (L x W x H)	2, 085 mm x 745 mm x 1, 090 mm
Seat Height	805 mm
Wheelbase	1, 400 mm
Minimum Ground Clearance	140 mm
Wet Weight	179 kg
Fuel Tank Capacity	14 L
Maximum Power	74.8 PS (55.0 kW) @ 9, 000 rpm
Rear Suspension	Swingarm (Link type suspension)
