Yamaha 2014 MT-07 Service Manual

CHASSIS SPECIFICATIONS
2-8
EAS20015
CHASSIS SPECIFICATIONS
Chassis
Frame type Diamond
Caster angle 24.80 °
Trail 90 mm (3.5 in)
Front wheel
Wheel type Cast wheel
Rim size 17M/C x MT3.50
Rim material Aluminum
Wheel travel 130 mm (5.1 in)
Radial wheel runout limit 1.0 mm (0.04 in)
Lateral wheel runout limit 0.5 mm (0.02 in)
Rear wheel
Wheel type Cast wheel
Rim size 17M/C x MT5.50
Rim material Aluminum
Wheel travel 130 mm (5.1 in)
Radial wheel runout limit 1.0 mm (0.04 in)
Lateral wheel runout limit 0.5 mm (0.02 in)
Front tire
Type Tubeless
Size 120/70 ZR17M/C (58W)
Manufacturer/model MICHELIN/PILOT ROAD 3
Manufacturer/model BRIDGESTONE/BT023F F
Wear limit (front) 1.6 mm (0.06 in)
Rear tire
Type Tubeless
Size 180/55 ZR17M/C (73W)
Manufacturer/model MICHELIN/PILOT ROAD 3A
Manufacturer/model BRIDGESTONE/BT023R M
Wear limit (rear) 1.6 mm (0.06 in)
Tire air pressure (measured on cold tires)
Loading condition 0–173 kg (0–381 lb)
Front 225 kPa (2.25 kgf/cm², 33 psi)
Rear 250 kPa (2.50 kgf/cm², 36 psi)
High-speed riding
Front 225 kPa (2.25 kgf/cm², 33 psi)
Rear 250 kPa (2.50 kgf/cm², 36 psi)
Front brake
Type Dual disc brake
Operation Right hand operation
Front disc brake
Disc outside diameter × thickness 282.0 × 4.5 mm (11.10 × 0.18 in)
Brake disc thickness limit 4.0 mm (0.16 in)
Brake disc runout limit (as measured on wheel) 0.10 mm (0.0039 in)

Yamaha 2014 MT-07 Specifications

General

Engine Type	Liquid-cooled, 4-stroke, DOHC, 4-valve
Displacement	689 cc
Bore x Stroke	80.0 mm x 68.6 mm
Compression Ratio	11.5:1
Maximum Torque	68.0 Nm (6.9 kg-m) @ 6, 500 rpm
Fuel System	Fuel Injection
Ignition System	TCI
Transmission	Constant Mesh, 6-speed
Final Drive	Chain
Front Suspension	Telescopic forks
Front Brake	Hydraulic dual disc, Ø 282 mm
Rear Brake	Hydraulic single disc, Ø 245 mm
Front Tyre	120/70 ZR17M/C (58W)
Rear Tyre	180/55 ZR17M/C (73W)
Dimensions (L x W x H)	2, 085 mm x 745 mm x 1, 090 mm
Seat Height	805 mm
Wheelbase	1, 400 mm
Minimum Ground Clearance	140 mm
Wet Weight	179 kg
Fuel Tank Capacity	14 L
Maximum Power	74.8 PS (55.0 kW) @ 9, 000 rpm
Rear Suspension	Swingarm (Link type suspension)
