Yamaha 2014 MT-07 Service Manual

TIGHTENING TORQUES
2-15
EAS30016
ENGINE TIGHTENING TORQUES
Item
Thread
size
Q’ty Tightening torque Remarks
Exhaust pipe nut M8 4 20 Nm (2.0 m·kgf, 14 ft·lbf)
Cylinder head stud bolt (exhaust
pipe)
M8 4 15 Nm (1.5 m·kgf, 11 ft·lbf)
Muffler bracket bolt M6 4 10 Nm (1.0 m·kgf, 7.2 ft·lbf)
Muffler bracket bolt M8 2 20 Nm (2.0 m·kgf, 14 ft·lbf)
Muffler cover bolt M6 3 10 Nm (1.0 m·kgf, 7.2 ft·lbf)
O
2
sensor
M12 1 25 Nm (2.5 m·kgf, 18 ft·lbf)
Starter motor terminal nut M6 1 7 Nm (0.7 m·kgf, 5.1 ft·lbf)
Engine ground lead bolt M6 1 10 Nm (1.0 m·kgf, 7.2 ft·lbf)
O
2
sensor coupler bracket bolt
M6 1 7 Nm (0.7 m·kgf, 5.1 ft·lbf)
Spark plug M10 2 13 Nm (1.3 m·kgf, 9.4 ft·lbf)
Exhaust camshaft sprocket bolt M7 2 24 Nm (2.4 m·kgf, 17 ft·lbf)
Intake camshaft sprocket bolt M7 2 24 Nm (2.4 m·kgf, 17 ft·lbf)
Exhaust camshaft cap bolt M6 6 10 Nm (1.0 m·kgf, 7.2 ft·lbf)
Intake camshaft cap bolt M6 6 10 Nm (1.0 m·kgf, 7.2 ft·lbf)
Timing chain tensioner bolt M6 2 10 Nm (1.0 m·kgf, 7.2 ft·lbf)
Timing chain tensioner cap bolt M6 1 7 Nm (0.7 m·kgf, 5.1 ft·lbf)
Timing mark accessing bolt M8 1 15 Nm (1.5 m·kgf, 11 ft·lbf)
Crankshaft end cover M36 1 10 Nm (1.0 m·kgf, 7.2 ft·lbf)
Cylinder head cover bolt M6 4 10 Nm (1.0 m·kgf, 7.2 ft·lbf)
Breather plate bolt M5 6 4.0 Nm (0.40 m·kgf, 2.9 ft·lbf)
Cylinder head bolt M10 6 See TIP.
Cylinder head bolt M6 2 See TIP.
Timing chain guide bolt M6 1 10 Nm (1.0 m·kgf, 7.2 ft·lbf)
Timing chain bolt (right side of cylin-
der head)
M6 1 10 Nm (1.0 m·kgf, 7.2 ft·lbf)
Starter clutch bolt M8 3 32 Nm (3.2 m·kgf, 23 ft·lbf)
Generator rotor bolt M12 1 70 Nm (7.0 m·kgf, 51 ft·lbf)
Generator cover bolt M6 2 12 Nm (1.2 m·kgf, 8.7 ft·lbf)
Generator cover bolt M6 8 12 Nm (1.2 m·kgf, 8.7 ft·lbf)
Stator coil bolt M6 3 10 Nm (1.0 m·kgf, 7.2 ft·lbf)
Crankshaft position sensor bolt M6 2 10 Nm (1.0 m·kgf, 7.2 ft·lbf)
Coupler and hose bracket bolt M6 1 10 Nm (1.0 m·kgf, 7.2 ft·lbf)
Starter motor bolt M6 2 10 Nm (1.0 m·kgf, 7.2 ft·lbf)
Starter motor front cover bolt M5 2 5 Nm (0.5 m·kgf, 3.6 ft·lbf)
Starter motor terminal and rear cov-
er nut
M6 1 11 Nm (1.1 m·kgf, 8.0 ft·lbf)
E
E
LT
E
LT
LT
E
LT
LT
LT
