Yamaha 2014 MT-07 Service Manual

LIGHTING SYSTEM
8-19
EAS30499
TROUBLESHOOTING
Any of the following fail to light: headlight, high beam indicator light, taillight, license plate light or meter
light.
TIP
• Before troubleshooting, remove the following part(s):
1. Rider seat
2. Passenger seat
3. Center cover
4. Fuel tank side covers
5. Fuel tank
6. Headlight assembly
NG →
OK ↓
NG →
OK ↓
NG →
OK ↓
NG →
OK ↓
NG →
OK ↓
NG →
OK ↓
1. Check the each bulbs and bulb
sockets condition.
Refer to “CHECKING THE BULBS
AND BULB SOCKETS” on page
8-126.
Replace the bulb(s) and bulb socket(s).
2. Check the fuses.
(Ignition, signaling system, head-
light, fuel injection system, and
main)
Refer to “CHECKING THE FUS-
ES” on page 8-127.
Replace the fuse(s).
3. Check the battery.
Refer to “CHECKING AND
CHARGING THE BATTERY” on
page 8-128.
• Clean the battery terminals.
• Recharge or replace the battery.
4. Check the main switch.
Refer to “CHECKING THE
SWITCHES” on page 8-123.
Replace the main switch/immobilizer unit.
5. Check the dimmer switch.
Refer to “CHECKING THE
SWITCHES” on page 8-123.
• The dimmer switch is faulty.
• Replace the left handlebar switch.
6. Check the pass switch.
Refer to “CHECKING THE
SWITCHES” on page 8-123.
• The pass switch is faulty.
• Replace the left handlebar switch.
