Yamaha 2014 MT-07 Service Manual

ELECTRICAL SPECIFICATIONS
2-11
EAS20016
ELECTRICAL SPECIFICATIONS
Voltage
System voltage 12 V
Ignition system
Ignition system TCI
Ignition timing (B.T.D.C.) 10.0 °/1200 r/min
Engine control unit
Model/manufacturer TBDFH8/DENSO
Ignition coil
Minimum ignition spark gap 6.0 mm (0.24 in)
Primary coil resistance 1.19–1.61 Ω
Secondary coil resistance 8.50–11.50 kΩ
Lean angle sensor output voltage
Less than 65° 0.4–1.4 V
More than 65° 3.7–4.4 V
AC magneto
Standard output 14.0 V, 29.3 A@5000 r/min
Stator coil resistance 0.128–0.192 Ω (W-W)
Rectifier/regulator
Regulator type Semi conductor-short circuit
Regulated voltage (DC) 14.1–14.9 V
Rectifier capacity 50.0 A
Battery
Model YTZ10S
Voltage, capacity 12 V, 8.6 Ah
Specific gravity 1.310
Manufacturer GS YUASA
Ten hour rate charging current 0.86 A
Headlight
Bulb type Halogen bulb
Bulb voltage, wattage × quantity
Headlight 12 V, 60.0 W/55.0 W × 1
Auxiliary light 12 V, 5.0 W × 1
Tail/brake light LED
Front turn signal light 12 V, 10.0 W × 2
Rear turn signal light 12 V, 10.0 W × 2
License plate light 12 V, 5.0 W × 1
Meter lighting LED
Indicator light
Neutral indicator light LED
Turn signal indicator light LED

Yamaha 2014 MT-07 Specifications

General

Engine Type	Liquid-cooled, 4-stroke, DOHC, 4-valve
Displacement	689 cc
Bore x Stroke	80.0 mm x 68.6 mm
Compression Ratio	11.5:1
Maximum Torque	68.0 Nm (6.9 kg-m) @ 6, 500 rpm
Fuel System	Fuel Injection
Ignition System	TCI
Transmission	Constant Mesh, 6-speed
Final Drive	Chain
Front Suspension	Telescopic forks
Front Brake	Hydraulic dual disc, Ø 282 mm
Rear Brake	Hydraulic single disc, Ø 245 mm
Front Tyre	120/70 ZR17M/C (58W)
Rear Tyre	180/55 ZR17M/C (73W)
Dimensions (L x W x H)	2, 085 mm x 745 mm x 1, 090 mm
Seat Height	805 mm
Wheelbase	1, 400 mm
Minimum Ground Clearance	140 mm
Wet Weight	179 kg
Fuel Tank Capacity	14 L
Maximum Power	74.8 PS (55.0 kW) @ 9, 000 rpm
Rear Suspension	Swingarm (Link type suspension)
