THROTTLE BODIES
7-9
EAS20070
THROTTLE BODIES
Removing the air filter case and throttle bodies
Order Job/Parts to remove Q’ty Remarks
Rider seat
Refer to “GENERAL CHASSIS (1)” on page
4-1.
Fuel tank top cover/Fuel tank covers/Fuel tank
center cover/Fuel tank front cover
Refer to “GENERAL CHASSIS (4)” on page
4-11.
Fuel tank Refer to “FUEL TANK” on page 7-1.
Air duct bracket
Refer to “AIR FILTER CASE VALVE” on
page 7-6.
Pivot shaft protector (left/right) Refer to “SWINGARM” on page 4-95.
1 Cylinder head breather hose 1
2 Throttle position sensor coupler 1 Disconnect.
10 Nm (1.0 m
•
kgf, 7.2 ft
•
Ibf)
T
.
R.
10 Nm (1.0 m
•
kgf, 7.2 ft
•
Ibf)
T
.
R
.
3.0 Nm (0.30 m
•
kgf, 2.2 ft
•
Ibf)
T
.
R.
3.0 Nm (0.30 m
•
kgf, 2.2 ft
•
Ibf)
T
.
R
.
3.0 Nm (0.30 m
•
kgf, 2.2 ft
•
Ibf)
T
.R.
4.5 Nm (0.45 m
•
kgf, 3.3 ft
•
Ibf)
T
.R
.
7 Nm (0.7 m
•
kgf, 5.1 ft
•
Ibf)
T
.
R
.
2
1
