Yamaha 2014 MT-07 Service Manual

IGNITION SYSTEM
8-4
EAS30492
TROUBLESHOOTING
The ignition system fails to operate (no spark or intermittent spark).
TIP
• Before troubleshooting, remove the following part(s):
1. Rider seat
2. Passenger seat
3. Center cover
4. Fuel tank side covers
5. Fuel tank
6. Drive sprocket cover
7. Headlight assembly
NG →
OK ↓
NG →
OK ↓
NG →
OK ↓
OK →
NG ↓
NG →
OK ↓
NG →
OK ↓
NG →
OK ↓
1. Check the fuses.
(Ignition, fuel injection system, and
main)
Refer to “CHECKING THE FUS-
ES” on page 8-127.
Replace the fuse(s).
2. Check the battery.
Refer to “CHECKING AND
CHARGING THE BATTERY” on
page 8-128.
• Clean the battery terminals.
• Recharge or replace the battery.
3. Check the spark plugs.
Refer to “CHECKING THE SPARK
PLUGS” on page 3-4.
Re-gap or replace the spark plug(s).
4. Check the ignition spark gap.
Refer to “CHECKING THE IGNI-
TION SPARK GAP” on page 8-134.
Ignition system is OK.
5. Check the ignition coils.
Refer to “CHECKING THE IGNI-
TION COILS” on page 8-134.
Replace the ignition coil(s).
6. Check the crankshaft position sen-
sor.
Refer to “CHECKING THE CRANK-
SHAFT POSITION SENSOR” on
page 8-135.
Replace the crankshaft position sensor.
7. Check the main switch.
Refer to “CHECKING THE
SWITCHES” on page 8-123.
Replace the main switch/immobilizer unit.
