132 Installation example of the standard drive module configuration
Required parts
Required tools
• Set of screw drivers (Torx and Pozidriv)
• Set of metric magnetic-end hexagon sockets
• Torque wrench
• Step drill bit for drilling the holes in the clear plastic shroud for input power cables.
Overall flowchart of the installation process
Drive module standard parts
• Drive module
• Fastening brackets (2 pcs)
• Pedestal guide plates (2 pcs)
• Telescopic extraction and insertion ramp
• Fastening screws and insulators in a plastic bag
• External control unit
Rittal parts / Alternative ABB parts
Rittal part code Qty
(pcs)
Description
TS 131 800 1 Enclosure without mounting plate, bottom plates and side panels. Includes
supports for installing air baffles.
TS 7967.000
(one set = four pieces)
1 Spacers for roof plates. / ABB roof
TS 8612.580 1 Punched section with mounting flange, outer mounting level for 800 mm
horizontal
Contact ABB for the
suitable filter
4 Air filter. Remove the filter mats.
Alternative ABB parts for Rittal parts
ABB air inlet kit 800 mm
3AUA0000117005 (IP20)
3AUA0000117009 (IP42)
2See section Air inlet kits on page 176.
ABB air outlet kit 800 mm
3AUA0000125203 (IP20 )
3AUA0000114968 (IP42)
2See section Air outlet kits on page 178.
Customer-made parts (not ABB or Rittal products)
Air baffles 4 See section Air baffles for the standard drive module on page 212.
Bottom plate 1 See section Bottom plate on page 211.
Step Task For instructions, see
1 Install the Rittal parts, drive bottom guide plate
and loose drive options in the drive module
cubicle.
Installing the drive module and LCL filter
module into a cabinet on page 133.
2 Install the auxiliary components (such as
mounting plates, air baffles, switches, busbars
etc.).
The component manufacturer’s instructions
Preventing the recirculation of hot air on page
52.
