ABB ACS880-34 User Manual

64 Guidelines for planning the electrical installation
 Typical power cable sizes
The table below gives copper and aluminum cable types with concentric copper shield for
the drives with nominal current. See also Terminal and entry data for the power cables on
page 193.
1) The cable sizing is based on max. 9 cables laid on a cable ladder side by side, three ladder type trays one
on top of the other, ambient temperature 30 °C (86 °F) PVC insulation, surface temperature 70 °C
(158 °F) (EN 60204-1 and IEC 60364-5-52). For other conditions, dimension the cables according to local
safety regulations, appropriate input voltage and the load current of the drive.
2) The cable sizing is based on NEC Table 310-16 for copper wires, 75 °C (167 °F) wire insulation at 40 °C
(104 °F) ambient temperature. Not more than three current-carrying conductors in raceway or cable or
earth (directly buried). For other conditions, dimension the cables according to local safety regulations,
appropriate input voltage and the load current of the drive.
Drive type
ACS880-
1434-
IEC
1)
US
2)
Cu cable
type
Al cable
type
Cu cable type Al cable type
mm
2
mm
2
AWG/kcmil AWG/kcmil
U
N
= 400 V
246A-3 3 × (3×95) 3 × (3×150) 2××500 MCM or 3×250 MCM 2×700 MCM or 3×350 MCM
293A-3 3 × (3×95) 3 × (3×150) 2×500 MCM or 3×250 MCM 2×700 MCM or 3×350 MCM
363A-3 3 × (3×95) 3 × (3×150) 2×500 MCM or 3×250 MCM 2×700 MCM or 3×350 MCM
505A-3 3 × (3×95) 3 × (3×150) 2×500 MCM or 3×250 MCM 2×700 MCM or 3×350 MCM
585A-3 3 × (3×95) 3 × (3×150) 2×500 MCM or 3×250 MCM 2×700 MCM or 3×350 MCM
650A-3 3 × (3×120) 3 × (3×185) 2×600 MCM or 3×300 MCM 3×400 MCM or 4×250 MCM
725A-3 3 × (3×150) 3 × (3×240) 2×700 MCM or 3×350 MCM 3×400 MCM or 4×250 MCM
U
N
= 500 V
240A-5 3 × (3×95) 3 × (3×150) 2×400 MCM or 3×4/0 2×600 MCM or 3×300 MCM
260A-5 3 × (3×95) 3 × (3×150) 2×400 MCM or 3×4/0 2×600 MCM or 3×300 MCM
302A-5 3 × (3×95) 3 × (3×150) 2×400 MCM or 3×4/0 2×600 MCM or 3×300 MCM
361A-5 3 × (3×95) 3 × (3×150) 2×400 MCM or 3×4/0 2×600 MCM or 3×300 MCM
414A-5 3 × (3×95) 3 × (3×150) 2×400 MCM or 3×4/0 2×600 MCM or 3×300 MCM
460A-5 3 × (3×95) 3 × (3×150) 2×400 MCM or 3×4/0 2×600 MCM or 3×300 MCM
503A-5 3 × (3×95) 3 × (3×150) 2×500 MCM or 3×250 MCM 2×700 MCM or 3×350 MCM
583A-5 3 × (3×120) 3 × (3×185) 2×600 MCM or 3×300 MCM 3×500 MCM or 4×300 MCM
U
N
= 690 V
142A-7 2 × (3×120) 3 × (3×120) 2×250 MCM or 3×2/0 2×350 MCM or 3×4/0
174A-7 2 × (3×120) 3 × (3×120) 2×250 MCM or 3×2/0 2×350 MCM or 3×4/0
210A-7 2 × (3×120) 3 × (3×120) 2×250 MCM or 3×2/0 2×350 MCM or 3×4/0
271A-7 2 × (3×120) 3 × (3×120) 2×250 MCM or 3×2/0 2×350 MCM or 3×4/0
330A-7 2 × (3×120) 3 × (3×120) 2×250 MCM or 3×2/0 2×350 MCM or 3×4/0
370A-7 2 × (3×120) 3 × (3×120) 2×300 MCM or 3×3/0 2×400 MCM or 3×4/0
430A-7 3 × (3×95) 3 × (3×120) 2×350 MCM or 3×4/0 2×500 MCM or 3×250 MCM
3AXD00000588487
