ABB ACS880-34 - Ordering Codes; Description, Installation and Technical Data of the FOCH Filters; Sine Filters; When is a Sine Filter Needed?

240 du/dt and sine filters
 Ordering codes
 Description, installation and technical data of the FOCH filters
See FOCH du/dt filters hardware manual (3AFE68577519 [English]).
Sine filters
 When is a sine filter needed?
See section Examining the compatibility of the motor and drive, page 58.
 Selection table
Sine filter types for the drive modules are given below.
* Combined value for drive and filter
 ABB ordering codes
 Derating
See section Deratings for special settings in the drive control program on page 186.
Filter type
Degree of
protection
ABB ordering code
FOCH0320-50 IP00 68612209
FOCH0320-52 IP22 3AXD50000030047
FOCH0260-70 IP00 68490308
FOCH0260-72 IP22 3AXD50000030048
FOCH-0610-70 IP00 68550505
Drive
module
type
ACS880-34-
Sine filter type Drive
module
type
ACS880-34-
Sine filter type Drive
module
type
ACS880-
34-
Sine filter type
U
N
= 400 V U
N
= 500 V U
N
= 690 V
246A-3 B84143V0230S229 240A-5 B84143V0230S229 142A-7 B84143V0130S230
293A-3 B84143V0390S229 260A-5 B84143V0230S229 174A-7 B84143V0207S230
363A-3 B84143V0390S229 302A-5 B84143V0390S229 210A-7 B84143V0207S230
442A-3 B84143V0390S229 361A-5 B84143V0390S229 271A-7 B84143V0207S230
505A-3 NSIN900-6 414A-5 B84143V0390S229 330A-7 NSIN485-6
585A-3 NSIN900-6 460A-5 NSIN900-6 370A-7 NSIN485-6
650A-3 NSIN900-6 503A-5 NSIN900-6 430A-7 NSIN485-6
3AXD00000588487
Filter type ABB ordering code
NSIN485-6 64254936
NSIN900-6 64254961
