180 Ordering information
Cooling fans
One or two cooling fans are to be installed inside the air outlet compartment to ensure
sufficient cooling of the cabinet.
600 mm / IP54
(IEC)
1 A-6-X-065 3AXD50000009189
Instruction code: 3AXD50000010004
Note: Fan to be ordered separately
600 mm / IP54
(UL)
1 A-6-X-066 3AXD50000010327
Instruction code: 3AXD50000010004
Note: Fan to be ordered separately
Enclosure width /
Degree of protection
Component Qty Ordering code
Name Data
IEC
400 mm / IP54 Fan RB4C-355/170 1 3AXD50000006934
Capacitor MSB MKP 6/603/E1679 1 3AXD50000006959
Connector SPB2,5/7 (2.5 mm2, 12AWG) 1 3AXD50000000723
Connector SC 2,5-RZ/7 (2.5 mm2, 12AWG) 1 3AXD50000000724
600 mm / IP54 Fan CRBB/4-400/188 1 3AXD50000006111
Capacitor MSB MKP 12/603/E1679 1 3AXD50000006885
Connector SPB2,5/7 (2.5 mm2, 12AWG) 1 3AXD50000000723
Connector SC 2,5-RZ/7 (2.5 mm2, 12AWG) 1 3AXD50000000724
Enclosure width /
Degree of protection
Qty Kit code Ordering code Illustration
