188 Technical data
High speed mode
Selection High speed mode of parameter 95.15 Special HW settings improves control
performance at high output frequencies. ABB recommends it to be selected with output
frequency of 120 Hz and above.
This table gives the drive module ratings for 120 Hz output frequency and the maximum
output frequency for each drive ratings when High speed mode in parameter
95.15 Special HW settings is enabled: With output frequencies smaller than this
recommended maximum output frequency, the current derating is less than the values
given in the table. Contact ABB for operation above the recommended maximum output
frequency or for the output current derating with output frequencies above 120 Hz and
below the maximum output frequency.
Drive
module
type
ACS880-34-
Deratings with selection High speed mode of parameter 95.15 Special HW settings
120 Hz output frequency Maximum output frequency
Nominal use Light-
duty use
Heavy-
duty use
Nominal use Light-
duty
use
Heavy-
duty use
fI
N
P
N
I
Ld
I
Hd
f
max
I
N
P
N
I
Ld
I
Hd
Hz A kW A A Hz A kW A A
U
N
= 400 V
246A-3 120 246 132 234 206 500 201 110 193 170
293A-3 120 293 160 278 246 500 240 132 229 203
363A-3 120 363 200 345 293 500 297 200 284 241
442A-3 120 442 250 420 363 500 362 250 346 299
505A-3 120 505 250 480 363 500 413 250 395 299
585A-3 120 585 315 556 442 500 479 315 458 364
650A-3 120 650 355 618 505 500 532 315 509 416
U
N
= 460 V
302A-5 120 302 250 hp 302 260 500 247 200 hp 249 214
U
N
= 500 V
240A-5 120 240 132 228 180 500 196 132 188 148
260A-5 120 260 160 247 240 500 213 160 203 198
361A-5 120 361 200 343 260 500 295 250 283 214
414A-5 120 414 250 393 361 500 339 250 324 297
460A-5 120 460 315 450 414 500 376 315 371 341
503A-5 120 503 355 492 460 500 412 315 405 379
U
N
= 690 V
142A-7 120 142 132 135 119 500 82 75 78 68
174A-7 120 174 160 165 142 500 100 110 95 82
210A-7 120 210 200 200 174 500 121 132 115 100
271A-7 120 271 250 257 210 500 156 160 148 121
330A-7 120 330 315 320 271 500 190 200 184 156
370A-7 120 370 355 360 330 500 213 250 207 190
430A-7 120 430 400 420 400 500 247 250 241 213
3AXD00000588487
f Output frequency
f
max
Maximum output frequency with High speed mode
U
N
Nominal voltage of the drive
I
N
Continuous rms output current. No overload capability at 40 °C (104 °F)
