Operation principle and hardware description 29

Operation principle and

hardware description

Contents of this chapter

This chapter describes the operating principle and construction of the drive module.

Operation principle

The ACS880-34 is a low-harmonic drive module for controlling asynchronous AC induction

motors, permanent magnet motors, AC induction servomotors and ABB synchronous

reluctance motors (SynRM motors).
