Installation example of the standard drive module configuration 133
Installing the drive module and LCL filter module into a
cabinet
See appendix Step-by-step drawings for an installation example of standard drive
configuration in Rittal TS 8 800 mm wide cabinet on page 243 and ACS880-34 quick
installation guide (3AXD500000212453 [English]).
• Attach the plinth to the floor.
• Attach the cabinet frame to the plinth.
• Make the bottom plate with 360-degree grounding entries for power cables.
• Attach the bottom plate to the cabinet.
• Attach the punched section to the back of the cabinet frame.
• Attach the mounting brackets to the punched section.
• Install the pedestal to the LCL filter module.
• Install the cooling fan to the LCL filter module.
• Attach the LCL filter module pedestal guide plate to the cabinet bottom plate.
• Attach the telescopic insertion ramp to the pedestal guide plate.
• To prevent the LCL filter module from falling, attach its lifting lugs with chains to the
cabinet frame.
• Push the LCL filter module carefully into the cabinet along the telescopic insertion
ramp. Work preferably with help from another person as shown below. Keep a
3 Attach the drive module and LCL filter module to
the cabinet
Step-by-step drawings for an installation
example of standard drive configuration in
Rittal TS 8 800 mm wide cabinet on page 243.
Connecting the power cables and installing the
shrouds on page 134
Connecting the power cables on page 93.
4 Connect the power cables and clear plastic
shrouds to the drive module.
Connect the power supply cable to the LCL filter
cooling fan.
5 Mount the external control unit. Mounting the external control unit, page 105
6 Connect the control cables. Connecting the control cables to the terminals
of the control unit, page 107
7 Install the remaining parts, for example, cabinet
doors, side plates, etc.
The component manufacturer’s instructions.
