Technical data 183
Technical data
Contents of this chapter
This chapter contains the technical specifications of the drive, for example, the ratings,
sizes and technical requirements, provisions for fulfilling the requirements for CE and
other markings.
Ratings
The nominal rating for the drive modules with 50 Hz and 60 Hz supply are given below.
IEC RATINGS
Drive type
ACS880-34-
Frame
size
Input
current
Output ratings
Nominal use Light-duty use Heavy-duty use
I
1
I
max
I
2
P
N
S
N
I
Ld
P
Ld
I
Hd
P
Hd
AAAkWkVAAkWAkW
U
N
= 400 V
246A-3 R11 212 412 246 132 170 234 132 206 110
293A-3 R11 257 492 293 160 203 278 160 246 132
363A-3 R11 321 586 363 200 251 345 200 293 160
442A-3 R11 401 726 442 250 306 420 250 363 200
505A-3 R11 401 726 505 250 350 480 250 363 200
585A-3 R11 505 884 585 315 405 556 315 442 250
650A-3 R11 569 1010 650 355 450 618 355 505 250
U
N
= 500 V
240A-5 R11 169 360 240 132 208 228 132 180 110
260A-5 R11 205 480 260 160 225 247 160 240 132
361A-5 R11 257 520 361 200 313 343 200 260 160
414A-5 R11 321 722 414 250 359 393 250 361 200
460A-5 R11 404 828 460 315 398 450 315 414 250
503A-5 R11 455 920 503 355 436 492 355 460 315
