Technical data 191
Fuses (UL Recognized)
UL Recognized fuses for branch circuit protection per NEC are listed below. Check that
the operating time of the fuse is below 0.1 seconds. The operating time depends on
the fuse type, supply network impedance and the cross-sectional area, material and length
of the supply cable. The fuses must be of the “non-time delay” type. Obey local
regulations.
Note 1: See also Implementing thermal overload and short-circuit protection on page 69.
Note 2: In multicable installations, install only one fuse per phase (not one fuse per conductor).
Note 3: Fuses with higher current rating than the recommended ones must not be used. Fuses with lower
current rating can be used.
Note 4: Fuses from other manufacturers must not be used.
Drive type
ACS880-34-
Input
current
(A)
Fuse
A V Manufacturer Size Type DIN 43653
U
N
= 400 V
246A-3 212 400 690 Bussmann 2 170M5408
293A-3 257 500 690 Bussmann 2 170M5410
363A-3 321 630 690 Bussmann 3 170M6410
442A-3 401 700 690 Bussmann 3 170M6411
505A-3 401 800 690 Bussmann 3 170M6412
585A-3 505 1000 690 Bussmann 3 170M6414
650A-3 569 1000 690 Bussmann 3 170M6414
U
N
= 500 V
240A-5 169 315 690 Bussmann 1 170M4410
260A-5 205 400 690 Bussmann 2 170M5408
302A-5 239 500 690 Bussmann 2 170M5410
361A-5 257 630 690 Bussmann 3 170M6410
414A-5 321 700 690 Bussmann 3 170M6411
460A-5 404 700 690 Bussmann 3 170M6411
503A-5 455 800 690 Bussmann 3 170M6412
U
N
= 600 V
142A-7 125 250 690 Bussmann 1 170M4409
174A-7 146 315 690 Bussmann 1 170M4410
210A-7 166 400 690 Bussmann 2 170M5408
271A-7 208 500 690 Bussmann 2 170M5410
330A-7 250 630 690 Bussmann 3 170M6410
370A-7 291 700 690 Bussmann 3 170M6411
430A-7 375 700 690 Bussmann 3 170M6411
