ABB ACS880-34 User Manual

192 Technical data
Dimensions, weights and free space requirements
* approximate (depends on the selected options)
Weight of the LCL filter module: 180 kg (396 lb)
The weight of the cabling panels of option +H381 is 30 kg (66 lb)
For requirements of free space around the drive module, see page 55.
Losses, cooling data and noise
The air flow direction is from bottom to top.
This table shows typical heat loss values, required air flow and noise at the nominal ratings
of the drive. The heat loss values can vary depending on voltage, cable conditions, motor
efficiency and power factor. To obtain more accurate values for given conditions, use ABB
DriveSize tool (http://new.abb.com/drives/software-tools/drivesize)
.
Standard drive module configuration (drive module + LCL filter module)
Frame
size
Height Width Depth Weight*
mm in mm in mm in kg lb
R11 1741 68.54 713 28.07 512 20.16 365 805
Optional selection +0B051+0H371 (without shrouds and full-size output power cable connection
terminals)
Frame
size
Height Width Depth Weight*
mm in mm in mm in kg lb
R11 1733 68.20 401 15.77. 506 19.92 161 355
Optional selection +H381 (full power cabling panels)
Frame
size
Height Width Depth Weight*
mm in mm in mm in kg lb
R11 1780 70.08 709 27.91 500 19.69 495 871
Weight of optional selections
Frame
size
+E208 +H356 +0H371 +H370 +0B051
kg lb kg lb kg lb kg lb kg lb
R11 3 7 2 4 -2.9 -6 2.9 6 -1.5 -3
Drive type Frame size Air flow Heat dissipation Noise
m
3
/h ft
3
/min W dB(A)
U
N
= 400 V
ACS880-34-246A-3 R11 2100 1279 5 280 75
ACS880-34-293A-3 R11 2100 1279 6 400 75
ACS880-34-363A-3 R11 2100 1279 8 000 75
ACS880-34-442A-3 R11 2100 1279 10 000 75
ACS880-34-505A-3 R11 2100 1279 10 000 75
ACS880-34-585A-3 R11 2100 1279 12 600 75
ACS880-34-650A-3 R11 2100 1279 14 200 75
U
N
= 500 V
ACS880-34-240A-5 R11 2100 1279 5 280 75
ACS880-34-260A-5 R11 2100 1279 6 400 75
ACS880-34-302A-5 R11 2100 1279 8 000 75
ACS880-34-361A-5 R11 2100 1279 8 000 75
ACS880-34-414A-5 R11 2100 1279 10 000 75
ACS880-34-460A-5 R11 2100 1279 12 600 75
ACS880-34-503A-5 R11 2100 1279 14 200 75
