Installation checklist 149
Installation checklist
Contents of this chapter
This chapter contains a list for checking the mechanical and electrical installation of the
drive module.
Installation checklist
Go through the checklist below together with another person.
WARNING! Obey the safety instructions in chapter Safety instructions. If
you ignore them, injury or death, or damage to the equipment can occur.
Check that …
Cabinet construction
The drive module is fastened properly to the cabinet. (See chapters Guidelines for planning the
cabinet installation, Installation example of the standard drive module configuration
Mechanical joints are tightened and not broken.
Parts are clean and painted surfaces not scratched.
The cabinet frame and parts which are in metal to metal contact with the frame (for example seams,
component fixing points on assembly plates, back of control unit mounting plate) are not finished
with non-conducting paint or material.
Degree of protection (IPxx)
