Technical data 195
Note 1: Motor cable longer than 100 m (492 ft) is allowed but then the EMC
Directive requirements may not be fulfilled, see section EMC compliance
(IEC/EN 61800-3:2004) on page 198..
Note 2: Longer motor cables cause a motor voltage decrease which limits the
available motor power. The decrease depends on the motor cable length and
characteristics. Contact ABB for more information. Note that a sine filter
(optional) at the drive output also causes a voltage decrease.
DC connection data
Drive type Capacitance (mF)
U
N
= 400 V
ACS880-34-246A-3 10,5
ACS880-34-293A-3 10,5
ACS880-34-363A-3 10,5
ACS880-34-442A-3 10,5
ACS880-34-505A-3 10,5
ACS880-34-585A-3 14,0
ACS880-34-650A-3 14,0
U
N
= 500 V
ACS880-34-240A-5 10,5
ACS880-34-260A-5 10,5
ACS880-34-302A-5 10,5
ACS880-34-361A-5 10,5
ACS880-34-414A-5 10,5
ACS880-34-460A-5 14,0
ACS880-34-503A-5 14,0
U
N
= 690 V
ACS880-34-142A-7 5,3
ACS880-34-174A-7 5,3
ACS880-34-210A-7 5,3
ACS880-34-271A-7 5,3
ACS880-34-330A-7 5,3
ACS880-34-370A-7 5,3
ACS880-34-430A-7 5,3
Control panel type
ACS-AP-W assistant control panel
Efficiency
Approximately 96.5% at nominal power level
Protection classes
Degree of protection
(IEC/EN 60529)
IP20. With option +0B051: IP00
Enclosure type (UL 50) UL Open Type
Overvoltage category
(IEC 60664-1)
III
Degree of protection
IP20 (UL Open Type),. With option +0B051: IP00 (UL Open Type).
