Installation instructions 91
Installation alternatives
You can install the drive module into a cabinet using different procedures depending on the
drive configuration.
Attaching the drive module and LCL filter module to a mounting
plate or wall
Attach the LCL filter module and the drive module to wall or a mounting plate at the
fastening points shown below.
You can attach the modules to Rittal TS 8 cabinet with the mounting brackets delivered
with the drive, see Step-by-step drawings for an installation example of standard drive
configuration in Rittal TS 8 800 mm wide cabinet on page 243.
Attaching the drive module to the LCL filter module
See chapter Step-by-step drawings for an installation example of standard drive
configuration in Rittal TS 8 800 mm wide cabinet on page 243.
Attaching the drive module and the LCL filter module to the cabinet
base
See chapter Step-by-step drawings for an installation example of standard drive
configuration in Rittal TS 8 800 mm wide cabinet on page 243.
Alternatives for grounding the drive module
You can ground the drive module from its top back to the cabinet frame with these
alternatives:
