ABB ACS880-34 User Manual

196 Technical data
Ambient conditions
Environmental limits for the drive are given below. The drive is to be used in a
heated, indoor, controlled environment.
Operation
installed for stationary
use
Storage
in the protective
package
Transportation
in the protective
package
Installation site altitude For neutral-grounded
TN and TT systems and
IT (unrounded) systems:
0 to 4000 m (13123 ft)
above sea level
Above 1000 m [3281 ft]),
see page 185.
--
Air temperature -15 to +55 °C
(5 to 131 °F).
No frost
allowed. See page 185.
-40 to +70 °C
(-40 to +158 °F)
-40 to +70 °C
(-40 to +158 °F)
Relative humidity 5 to 95% Max. 95% Max. 95%
No condensation allowed. Maximum allowed relative humidity is 60% in the
presence of corrosive gases.
Contamination levels IEC/EN 60721-3-3:2002:
Classification of
environmental
conditions- Part 3-3:
Classification of groups
of environmental
parameters and their
severities - Stationary
use of weather protected
locations
IEC 60721-3-1:1997 IEC 60721-3-2:1997
Chemical gases Class 3C2 Class 1C2 Class 2C2
Solid particles Class 3S2. No
conductive dust allowed.
Class 1S3. (packing
must support this,
otherwise 1S2)
Class 2S2
Pollution degree 2
Atmospheric pressure 70 to 106 kPa
0.7 to 1.05 atmospheres
70 to 106 kPa
0.7 to 1.05 atmospheres
60 to 106 kPa
0.6 to 1.05 atmospheres
Vibration
IEC 60068-2-6:2007,
EN 60068-2-6:2008
Environmental testing Part 2-
6: Tests –Test Fc: Vibration
(sinusoidal)
Max. 0.1 mm (0.004 in.)
(10 to 57 Hz),
max. 10 m/s
2
(33 ft/s
2
)
(57 to 150 Hz) sinusoidal
Max. 1 mm (0.04 in.)
(5 to 13.2 Hz),
max. 7 m/s
2
(23 ft/s
2
)
(13.2 to 100 Hz)
sinusoidal
Max. 3.5 mm (0.14 in.)
(2 to 9 Hz),
max. 15 m/s
2
(49 ft/s
2
)
(9 to 200 Hz) sinusoidal
Shock
IEC 60068-2-27:2008,
EN 60068-2-27:2009
Environmental testing - Part 2-
27: Tests - Test Ea and
guidance: Shock
Not allowed With packing max.
100 m/s
2
(330 ft./s
2
),
11 ms
With packing max.
100 m/s
2
(330 ft./s
2
),
11 ms
Free fall Not allowed 100 mm (4 in.) 100 mm (4 in.)
Materials
Drive enclosure • PC/ABS 2.5 mm, color NCS 1502-Y (RAL 9002 / PMS 420 C)
• hot-dip zinc coated steel sheet 1.5 to 2.5 mm, thickness of coating
100 micrometers, color NCS 1502-Y
Air baffles for RIttal cabinet See section Material of the air baffles on page 213.
