du/dt and sine filters 239
du/dt and sine filters
Contents of this chapter
This chapter describes how to select du/dt and sine filters for the drive.
du/dt filters
When is a du/dt filter needed?
See section Examining the compatibility of the motor and drive, page 58.
Selection table
du/dt filter types for the drive modules are given below.
Drive module
type
ACS880-34-
du/dt filter type Drive module
type
ACS880-34-
du/dt filter type Drive module
type
ACS880-34-
du/dt filter type
U
N
= 400 V U
N
= 500 V U
N
= 690 V
246A-3 FOCH0260-7x 240A-5 FOCH0260-7x 142A-7 FOCH0260-7x
293A-3 FOCH0260-7x 260A-5 FOCH0260-7x 174A-7 FOCH0260-7x
363A-3 FOCH0320-5x 302A-5 FOCH0320-5x 210A-7 FOCH0260-7x
442A-3 FOCH0320-5x 361A-5 FOCH0320-5x 271A-7 FOCH0260-7x
505A-3 FOCH-0610-70 414A-5 FOCH0320-5x 330A-7 FOCH-0610-70
585A-3 FOCH-0610-70 460A-5 FOCH0320-5x 370A-7 FOCH-0610-70
650A-3 FOCH-0610-70 503A-5 FOCH-0610-70 430A-7 FOCH-0610-70
3AXD00000588487
