Technical data 193
The cooling air temperature rises 30 degrees Celsius when it goes through the drive
module if the temperature of the input cooling air is 40 degrees Celsius.
Terminal and entry data for the power cables
The maximum accepted cable size is 4 × (3 × 240) mm
2
or 4 × (3 × 500 AWG). Screw size
for connecting busbars to the drive module input and output busbars: M12, tightening
torque 50...75 N·m.
 Units with optional cabling panels (+H381)
The maximum accepted cable size is 4 × (3 × 240) mm
2
or 4 × (3 × 500 AWG). The
cabling panels are connected to the drive module busbars with M12 serpress nuts,
tightening torque 30 N·m (20 lbf·ft).
Input, motor and brake resistor cable terminal sizes and tightening torques are given
below.
Two-hole 1/2 inch diameter cable lugs can be used.
 Units without full-size output cable connection terminals (+0H371)
and with a common mode filter (+E208)
It is possible to use the maximum cable size (4 × [3 × 240] mm2 or 4 ×[(3 × 500 AWG])
only with special cable lugs and additional insulation. For more information, contact your
local ABB representative.
Terminal data for the control cables
See page 115 or 128.
ACS880-34-142A-7 R11 2100 1279 5 280 75
ACS880-34-174A-7 R11 2100 1279 6 400 75
ACS880-34-210A-7 R11 2100 1279 8 000 75
ACS880-34-271A-7 R11 2100 1279 10 000 75
ACS880-34-330A-7 R11 2100 1279 12 600 75
ACS880-34-370A-7 R11 2100 1279 14 200 75
ACS880-34-430A-7 R11 2100 1279 16 000 75
L1/U1, L2/V1, L3/W1, T1/U2, T2/V2, T3/W2, UDC+, UDC- Grounding busbar
Screw Tightening torque Screw Tightening torque
N-m lbf·ft N-m lbf·ft
M12 1/2 50...75 37...55 M10 3/8 30...44 22...32
Electrical power network specification
Voltage (U
1
) ACS880-34-xxxx-3 drive modules: 380…415 V AC phase +10%/-15%. This
is indicated in the type designation label as typical input voltage level
3400VAC.
ACS880-34-xxxx-5 drive modules: 380...500 V AC 3-phase +10%/-15%. This
is indicated in the type designation label as typical input voltage levels
3 400/480/500 V AC.
ACS880-34-xxxx-7 drive modules: 525…690 V AC 3-phase +10%/-15%. This
is indicated in the type designation label as typical input voltage levels
3 525/600/690 (600 UL, CSA) V AC .
Drive type Frame size Air flow Heat dissipation Noise
m
3
/h ft
3
/min W dB(A)
~
~
~
