Installation example with full cabling panels (option +H381) 139
Overall flowchart of the installation process
Installing the mechanical accessories into the cabinet
See appendix Step-by-step drawings for an installation example of standard drive
configuration in Rittal TS 8 800 mm wide cabinet on page 243 for these steps:
• Attach the plinth to the floor.
• Attach the cabinet frame to the plinth.
• Make the bottom plate with 360-degree grounding entries for power cables.
• Attach the bottom plate to the cabinet.
• Attach the punched section to the back of the cabinet frame.
• Attach the mounting brackets to the punched section.
To install the full cabling panels to the cabinet frame (see the drawings on the next page):
1. Install the Rittal punched sections TS 8612.560 to which the output cabling panel and
the input cabling panel will be attached.
2. Install the air baffles.
3. Attach the output cabling panel to the punched sections.
4. Install the side guides to the output cabling panel (2 screws for each guide).
5. Attach the grounding busbar to the input cabling panel.
6. Install the side guides to the input cabling panel (2 screws for each side guide).
7. Attach the input cabling panel to the punched sections.
8. Install the telescopic extraction and insertion ramp as shown in the appendix.
Step Task For instructions, see
1 Install the Rittal parts and drive module
mechanical accessories into the cabinet.
Installing the mechanical accessories into the
cabinet on page 139.
3 Connect the power cables to the cabling panels. Connecting the power cables, page 141.
4 Install the drive module into the cabinet. Installing the drive module into the cabinet,
page 144
5 Install the external control unit. Mounting the external control unit, page 105
6 Connect the control cables. Connecting the external control unit to the
drive module, page 107
7 Install the remaining parts, for example, cabinet
doors, side plates, etc.
The component manufacturer’s instructions
