190 Technical data
Fuses (IEC)
aR fuses for protection against short-circuit in the input power cable or drive are listed
below.
Note 1: See also Implementing thermal overload and short-circuit protection on page 69.
Note 2: In multicable installations, install only one fuse per phase (not one fuse per conductor).
Note 3: Fuses with higher current rating than the recommended ones must not be used. Fuses with lower
current rating can be used.
Note 4: Fuses from other manufacturers can be used if they agree with the ratings and the melting curve of the
fuse does not exceed the melting curve of the fuse mentioned in the table.
Ultrarapid (aR) fuses
Drive type
ACS880-34-
Input
current
(A)
Fuse
AA
2
s V Manufacturer Type DIN 43653 Size
U
N
= 400 V
246A-3 212 400 74 000 690 Bussmann 170M5408 2
293A-3 257 500 145 000 690 Bussmann 170M5410 2
363A-3 321 630 210 000 690 Bussmann 170M6410 3
442A-3 401 700 300 000 690 Bussmann 170M6411 3
505A-3 401 800 465 000 690 Bussmann 170M6412 3
585A-3 505 1000 945 000 690 Bussmann 170M6414 3
650A-3 569 1000 945 000 690 Bussmann 170M6414 3
U
N
= 500 V
240A-5 169 315 42 000 690 Bussmann 170M4410 1
260A-5 205 400 74 000 690 Bussmann 170M5408 2
302A-5 257 500 145 000 690 Bussmann 170M5410 2
361A-5 321 630 210 000 690 Bussmann 170M6410 3
414A-5 404 700 300 000 690 Bussmann 170M6411 3
460A-5 455 700 300 000 690 Bussmann 170M6411 3
503A-5 513 800 465 000 690 Bussmann 170M6412 3
U
N
= 690 V
142A-7 123 250 21 000 690 Bussmann 170M4409 1
174A-7 149 315 42 000 690 Bussmann 170M4410 1
210A-7 186 400 74 000 690 Bussmann 170M5408 2
271A-7 232 500 145 000 690 Bussmann 170M5410 2
330A-7 293 630 210 000 690 Bussmann 170M6410 3
370A-7 330 700 300 000 690 Bussmann 170M6411 3
430A-7 375 700 300 000 690 Bussmann 170M6411 3
