138 Installation example with full cabling panels (option +H381)
Required parts
The parts are used in this installation example:
Required tools
• Set of screw drivers (Torx and Pozidriv)
• Set of metric magnetic-end hexagon sockets
• Torque wrench with a 500 mm (20 in.) or 2 × 250 mm (2 × 10 in.) long extension bar
Drive module standard parts
• Drive module and LCL filter module
• Top guide plate
• Fastening brackets (2pcs)
• Grounding busbar
• Pedestal guide plates (2 pcs)
• Telescopic extraction and insertion ramp
• Fastening screws in a plastic bag
• External control unit
Drive module options
Option code Qty
(pcs)
Description
+H381 1 Full power cabling panels
Rittal parts and alternative ABB parts
Rittal part code Qty
(pcs)
Description
TS 8438.510 1 Enclosure without mounting plate, bottom plates and side panels.
TS 8108.235 1 Side panels for the cabinet
SZ/DK 7967.000 (one
set = four pieces) +
additional spacers
1 Spacers for roof plate. Alternative ABB roof (3AUA0000125203 [IP20],
AUA0000114968 [IP42]), see section Air outlet kits on page 178.
TS 8612.560 (one set =
four pieces)
1 Punched section with mounting flange, outer mounting level for 600 mm
horizontal
TS 8612.580 (one set =
four pieces)
1 Punched section with mounting flange, outer mounting level for 800 mm
horizontal
SK 3243.200 /
ABB 3AUA0000117002
(IP20)
ABB 3AUA0000117007
(IP42)
4 /
2
Air filter 323 mm × 323 mm. Remove the filter mat according to the
manufacturer’s instructions.
Alternative ABB air filters (3AUA0000117002 [IP20], 3AUA0000117007
[IP42]), see section Air inlet kits page 176.
Customer-made parts (not ABB or Rittal products)
Air baffles 4 See section Air baffles for the standard drive module on page 212 for the
dimension drawings of the air baffles required in the cabinet.
Cabinet bottom plate 1 See section Bottom plate on page 211 for the dimension drawing of a
customer-made bottom plate.
