1 - 5
FEATURES
MULTIFUNCTION DISPLAY
15. FUEL TANK CAPACITY AND RESERVE FUEL GAUGE
The digital fuel gauge shows the capacity of the fuel tank. As the
fuel level drops, the lines on the gauge will become closer and
closer to the "E" reserve area.
From the moment in which the last line starts fl ashing, the vehi-
cle has a fuel range of about 3 litres.
16. LIGHT (ABS)
The anti-lock braking system of brakes goes on when starting to
check the system and turns off if the check outcome is positive.
17. RIGHT DIRECTION INDICATOR LIGHT (GREEN)
It goes on when the left direction indicator light is activated.
54 6 7 8 9
16
11
10
13
14
15
12
2
1
3
17
