Benelli TRK 502 Service Station Manual

4 - 131
FAIRING
REMOVAL OF FUEL TANK
Park the bike on a level surface.
IMPORTANT NOTICE
Prop the bike on suitable supports so that it cannot fall.
Remove:
• Rider and passenger seats, see chapter entitled “Removal
of rider and passenger seats, Chapter 4”.
• Movable windscreen, see chapter entitled “Removal of
movable windscreen, Chapter 4”.
• Front fairing, see chapter entitled “Removal of front fair-
ing, Chapter 4”.
• Tank fairing, see chapter entitled “Removal of tank fairing,
Chapter 4”.
• The fi xing screws of the tank (10*) and (1*) to the frame Fig.
C
C
10*
1*
COPY - Moto GB - Grant Martland - grantmartland@motogb.co.uk
