5 - 28
V
AL
VE OIL SEAL REMOV
AL- INST
ALLA
TION
Remove:
Once the valve has been removed, using the special tool (*) to
take out the oil seal (AA) Fig. B.
(*) T
ool for valve oil seal removal
Install:
Proceed to install the oil seal (AA) Fig. D using the special tool
** Fig. C.
(**) V
alve oil seal insertion pad (**)
Code:R180197025000
B
*
AA
C
**
HEAD DISTRIBUTION
D
COPY - Moto GB - Grant Martland - grantmartland@motogb.co.uk
280
282
