TRANSMISSION CHAIN AND SWINGING ARM
TRANSMISSION CHAIN REMOVAL
NOTE:________________________________
Prop the bike on suitable supports so that it cannot fall.
Remove the parts in the indicated order.
• Chain pinion cover, refer to chapter “Removal of the chain
pinion cover, Chapter 4”.
Detach:
• The transmission chain
(with a suitable tool for transmission chains (A) Fig. A, or with the
dedicated tool according to the transmission chain manufactur-
er’s specifi cations.
