3 - 49
FUSES
The following procedure applies to all fuses.
IMPORTANT NOTICE
Bring the start switch to the OFF position.
Remove:
• Rider and passenger seats, see chapter “Removal of rider
and passenger seats, Chapter 4”.
Check:
• The fuse
Connect the pocket tester to the fuse and check the continuity.
NOTE:__________________________________________
Set the selector switch of the tester on “
Ω x 1”
• If the pocket tester indicates “∞”, replace the fuse.
Replace:
• The blown fuse.
- Position the main selector switch at “OFF”.
- Install a new fuse with the correct amperage.
- Switch on the switches to check that the electrical circuit
functions.
- If the fuse blows immediately, check the electrical circuit.
WARNING
Never use fuses with aN amperage different from those
specifi ed. The use of improvised techniques or fuses with
different amperages could cause irreversible damage to the
electrical system, or cause functioning defects of the light-
ing system and the ignition system and eventually cause a
fi re.
ELECTRICAL SYSTEM
