Benelli TRK 502 Service Station Manual

5 - 87
Assemble:
• the phase sensor (7*)
• the fastening screws (6*) to the following torque: B:
T
.
R
.
Torque 12 N*m
Measure:
• the distance (A) between the phase sensor (7*) and the
pick-up on the fl ywheel magnet Fig. B.
NOTE:_________________________________
Use a thickness gauge to take this measurement
B
A
STARTING
PHASE SENSOR INSTALLATION
7*
6*
