3 - 57
ELECTRICAL SYSTEM
SUBSTITUTION OF THE FRONT INDICATORS
Place the motorcycle on a fl at, level fl oor.
IMPORTANT NOTICE
Prop the motorcycle on suitable supports so that it cannot
fall.
Remove:
• Mobile windscreen, refer to chapter “Removal of mobile
windscreen, Chapter 4”.
• Front fairing, refer to chapter “Removal of front fairing,
Chapter 4”.
• Lighting unit, refer to chapter “Removal of the lighting
unit, Chapter 4”.
NOTE:_________________________________
The following procedure is applicable to both front indica-
tors
Remove:
• the support of the front indicators (1) Fig. A
• Remove the indicators.
Install:
• Proceed using the opposite order to removal.
A
1
1
