—————— TPD32-EV ——————

172

EXAMPLE(PIPEMILL)

DRIVE

MASTER

LINE SPEED

DRIVE

SLAVE

Analog

output

Analog

input

Figure 6.7.4.2: Droop function example

Examplesetting:  ---->Pourpose:Torqueofmotor1hastobeequaltotorqueofmotor2

DriveMaster Driveslave

  Analoginput1=Speedref1   Analoginput1=Speedref1

  Analogoutput1=Tcurrref   Analoginput2=Loadcomp

        Enabledroop=enables

        Droopgain=5%

        Drooplter=100ms

        Drooplimit=1000
