—————— Instruction manual ——————
479
A1.4 Pulse transformers
Pulsetransformerswiththefollowingcharacteristicsareavailableuponrequest:
PULSE TRANS-
FORMERS
Electrical diagram and code
Rated working volt-
age [Vrms]
Imax secondary winding
Transformation ratio
(P:S:S)
[A] [
arms]
PTD1 ESE5948-1 S5C370 500 1,2 Peak 0,75 3 : 1
PTD2 ESE5948-2 S5C371 500 1,2 Peak 0,5 3 : 1 : 1
PTD1-1 ESE5948-3 S5C372 750 1,2 Peak 0,75 3 : 1
PTD2-1 ESE5948-4 S5C373 750 1,2 Peak 0,5 3 : 1 : 1
PTD1-1K ESE5948-5 S5C374 1000 1,2 Peak 0,75 3 : 1
PTD2-1K ESE5948-6 S5C375 1000 1,2 Peak 0,5 3 : 1 : 1
Start-uppulsesare“pulsetrains”withatotaldurationof1msandfrequencyofapprox.12kHz.RFIRresistors
aredimensionedtohavepeakgatecurrentvaluesofbetween600mAand900mA..
Figure A1.4.1: Typical connection for PTDX-X transformers
+22V typ.
47R
SCR
3:1
0,1
F
Pulsetransformer PTD1-X
0V
R
P
T
K P T 1 1
G
K
R
R
FIR
+22V typ.
47R
SCR11
3:1:1
0,1
F
PulsetransformerPTD2-X
P
K P T1 1
G
3R9
R
47R
0,1
F
G0
K
3R9
SCR12
0V
R
T
R
FIR
K
A1.5 Current transducers (CT or TA)
ThearmaturecurrentofthemotorismeasuredbytwoACcurrenttransducersinsertedonthelinesideofthe
powerbridge;see,forexample,("Figure9.4.4:ESE5771TPD32-EV-CU-230...690-THY1-XX_1"onpage425).
Transducerswithdifferentprimary/secondarycurrentratiosareavailableonthemarketandcanbeusedwith
theCU.TheTPD32-..seriesusesaCTwithstandardcurrentvaluesof0.4Aor0.5Aonthesecondarywinding.
Werecommendtheuseofcurrenttransducerswithasecondarycurrentofnotmorethan1A.
Someofthecurrenttransducersavailableuponrequestarelistedbelowwiththerelativetechnicaldata:
TAS2-1600A/0,4A usedfor1000A≤IdN≤1800A (codeS7H22)
TAS2-2400A/0,5A usedfor2000A≤IdN≤2700A (codeS7H23)
TAS3-4000A/0,5A usedfor2900A≤IdN≤3300A (codeS7H30)
Electricaldata
Type
Rated voltage and
frequency
Winding
ratio
Rated primary
current
Rated secondary
current
Rated power Maximum bar opening
Measurement
accuracy
class
TAS2-1600A/0,4A
700Vrms
40 ... 60Hz
1:4000 1600A 0,4A 20VA
60mm x 15mm
[2.36” x 0.59”]
1
TAS2-2400A/0,5A 1:4800 2400A 0,5A 20VA
60mm x 15mm
[2.36” x 0.59”]
1
TAS3-4000A/0,5A 1:8000 4000A 0,5A ≥ 20VA
103mm x 60mm
[4.05” x 2.36"]
1
