gefran TPD32-EV-...-4B User Manual

—————— Instruction manual ——————
97
TPD32 EV
Standard sizes
Converter rated current
Rated inductance with
Ukd = 2%
Rated inductance with
Ukd = 4%
Rated current inductance
[A] [µH] [µH] [A]
TPD32-EV-690/...-1700-…-E 1700 15.2 30.5 1464
TPD32-EV-690/...-2000-…-E 2000 12.9 25.9 1722
TPD32-EV-690/...-2400-…-E 2400 10.8 21.6 2066
TPD32-EV-690/...-2700-…-E 2700 9.6 19.2 2325
TPD32-EV-690/...-3300-…-E 3300 7.8 15.7 2841
Mains voltage 575V, 3ph, 60 Hz
TPD32-EV-.../...-280-..-B 280 77.0 154.1 241
TPD32-EV-.../...-350-..-B 350 61.6 123.3 301
TPD32-EV-.../...-420-..-B 420 51.4 102.7 362
TPD32-EV-.../...-500-..-B 500 43.1 86.3 431
TPD32-EV-.../...-560-..-B 650 33.2 66.4 560
TPD32-EV-575/…-700-...-C 700 30.8 61.6 (**) 603
TPD32-EV-575/…-1000-...-C 1000 21.6 43.1 (**) 861
TPD32-EV-575/...-1050-…-C 1050 20.5 41.1 904
TPD32-EV-575/...-1300-...-D 1300 16.6 33.2 1119
TPD32-EV-575/...-1600-...-D 1600 13.5 27.0 1378
TPD32-EV-575/...-2000-...-D 2000 10.8 21.6 1722
TPD32-EV-575/...-2300-...-D 2300 9.4 18.8 1980
TPD32-EV-690/...-1010-…-E 1010 21.4 42.7 870
TPD32-EV-690/...-1400-…-E 1400 15.4 30.8 1205
TPD32-EV-690/...-1700-…-E 1700 12.7 25.4 1464
TPD32-EV-690/...-2000-…-E 2000 10.8 21.6 1722
TPD32-EV-690/...-2400-…-E 2400 9.0 18.0 2066
TPD32-EV-690/...-2700-…-E 2700 8.0 16.0 2325
TPD32-EV-690/...-3300-…-E 3300 6.5 13.1 2841
Table 4.10.4: Mains chokes for 690 Vac input supply
TPD32 EV
Standard sizes
Converter rated current
Rated inductance with
Ukd = 2%
Rated inductance with
Ukd = 4%
Rated current inductance
[A] [µH] [µH] [A]
Mains voltage 690V, 3ph, 50 Hz
TPD32-EV-690/…-560-...-C 560 55.5 110.9 482
TPD32-EV-690/…-700-...-C 700 44.4 88.7 603
TPD32-EV-690/…-900-...-C 900 34.5 69.0 775
TPD32-EV-690/...-1300-...-D 1300 23.9 47.8 1119
TPD32-EV-690/...-1600-...-D 1600 19.4 38.8 1378
TPD32-EV-690/...-1900-...-D 1900 16.3 32.7 1636
TPD32-EV-690/...-2100-...-D 2100 14.8 29.6 1808
TPD32-EV-690/...-1010-…-E 1010 30.8 61.5 870
TPD32-EV-690/...-1400-…-E 1400 22.2 44.4 1205
TPD32-EV-690/...-1700-…-E 1700 18.3 36.5 1464
TPD32-EV-690/...-2000-…-E 2000 15.5 31.1 1722
TPD32-EV-690/...-2400-…-E 2400 12.9 25.9 2066
TPD32-EV-690/...-2700-…-E 2700 11.5 23.0 2325
TPD32-EV-690/...-3300-…-E 3300 9.4 18.8 2841
Mains voltage 690V, 3ph, 60 Hz
TPD32-EV-690/…-560-...-C 560 46.2 92.4 (**) 482
TPD32-EV-690/…-700-...-C 700 37.0 74.0 603
TPD32-EV-690/…-900-...-C 900 28.8 57.5 (**) 775
TPD32-EV-690/...-1300-...-D 1300 19.9 39.8 1119
TPD32-EV-690/...-1600-...-D 1600 16.2 32.4 1378
TPD32-EV-690/...-1900-...-D 1900 13.6 27.2 1636
TPD32-EV-690/...-2100-...-D 2100 12.3 24.7 1808
TPD32-EV-690/...-1010-…-E 1010 25.6 51.3 870
TPD32-EV-690/...-1400-…-E 1400 18.5 37.0 1205
TPD32-EV-690/...-1700-…-E 1700 15.2 30.5 1464
TPD32-EV-690/...-2000-…-E 2000 12.9 25.9 1722
TPD32-EV-690/...-2400-…-E 2400 10.8 21.6 2066
TPD32-EV-690/...-2700-…-E 2700 9.6 19.2 2325
TPD32-EV-690/...-3300-…-E 3300 7.8 15.7 2841
