—————— Instruction manual ——————
207
6.12 I/O CONFIG
ENC 1 ENC 2
3456789101112131415161718192012
23 24 25 26 27 28 29 30 31 32 33 34 37 38 39 40 41 4221 22
Digital input 2
Digital input 1
Digital input 3
Digital input 4
Com digital inputs A
Analog output 1
Analog output 2
Com analog output 1
Com digital outputs A
Digital output 1
Digital output 2
Digital output 3
Digital output 4
Supply dig outputs A
TBO "A” integrated
Com analog output 2
12345678910 11 12 13 14 15
XB
1
2
19
20
TBO
Analog output 3
Com analog output 3
Analog output 4
Com analog output 4
Com digital outputs B
Digital output 5
Digital output 6
Digital output 7
Digital output 8
Supply dig outputs B
Digital input 5
Digital input 6
Digital input 7
Digital input 8
Com digital inputs B
TBO "B"
Analog input 1
Analog input 2
Analog input 3
Figure 6.12.1: Arrangement of the programmable I/O
Apartfromtheterminalswhichhavexedfunctions(e.g.forEnables),theconvertersoftheTPD32-EVseries
providethepossibilityofassigningfreelyprogrammableinputs/outputstoparticularfunctions.Thiscaneither
becarriedoutviathekeypad,theserialinterfaceoranybusconnectionpresent.
Thefreelyprogrammableinputs/outputsarefactorysetforassignmenttothemostfrequentlyrequiredfunctions.
However,thesecanbemodiedbytheuseraccordinglytomeettherequirementsoftheapplicationnathand.
Thedeviceinputs/outputsaresubdividedasfollows:
 -converterwithintegratedTBO“A”:
 3 Analoginputs(1...3),designedasdifferentialinputs
 2 Analogoutputs(1and2)withcommonreferencepoint
 4 Digitaloutputs(1...4)withcommonreferencepointandcommonvoltagesupply
 4 Digitalinputs(1...4)withcommonreferencepoint.
Whenotherdigitalinputs/outputsand/oranalogoutputsarerequired,togetherwiththealreadyexistingones,
theTBOoptioncardhastobeused,whichisinsertedontheconverterregulationcard.Aconvertercardcan
alsobemounted(seegure):
 -withTBO“B”optioncard:
Option“B”: 2 Analogoutputs(3and4)withcommonreferencepoint
 4 Digitaloutputs(5...8)withcommonreferencepointandcommonvoltagesupply
 4 Digitalinputs(5...8)withcommonreferencepoint.
note!  Ifparametersareassignedtoparticularterminals,theparametervalue(e.g.speedreference
value)canonlybeenteredviathisterminalandnotviathekeypadorbus.
