—————— Instruction manual ——————
475
APPENDIX 1 - TPD32-EV-CU: CONTROL UNIT
General description
TheTPD32-EV-CU-…isanelectroniccontrolunitdesignedforusewithoneormoresix-pulsetwoorfour-
quadrantpowerbridgeSCRAC/DCconverters.Itissuppliedasastand-aloneunitforsystemsthatalreadyhave
apowerbridge.
Thecontrolunitregulatesthearmaturevoltageandcurrent,generatesSCRgatecommandsignalsandalsocon-
tainsa40Aor70Aeldpowersupplycircuit.Itissuitableforpowerbridgesconnectedtoa230VACto690
VAC50/60Hzthree-phasevoltagesupply.Itinterfacesdirectlywiththethree-phasepowerline,thearmature
voltageandarmaturecurrent,measuredbytwocurrenttransducersthatmustbeincludedonthepowerbridge.
Itcoversarmaturecurrentsrangingfrom4A
dcto20,000Adc.
Figure A1.1: Typical single-wire connection diagram
FWD
REV
DC Motor
Motor
Field
AC Mains
CT-U
and
CT-W
Speedfeedback
Gate signals
AC feedback
Current feedback
Gate signals
Pulse
transformers
D
C
W
V
U
C1 D1
U1 V1
1
2
3
4
5
6
7
8
KPKPT31
40A or 70A
Field
Supply
TPD32-EV-CU-...
KPT11
Fieldsupply
DC feedback
