—————— TPD32-EV ——————
280
Pad B Bit 9
546 0 1 0 0
Pad B Bit 10
547 0 1 0 0
Pad B Bit 11
548 0 1 0 0
Pad B Bit 12
549 0 1 0 0
Pad B Bit 13
550 0 1 0 0
Pad B Bit 14
551 0 1 0 0 *****
Pad B Bit 15
552 0 1 0 0
*Theseparameterscanbesetonaprogrammableanaloginputs.
** Theseparameterscanbesetonaprogrammableanalogoutput.
***Theseparameterscanbesetonaprogrammabledigitalinput.
****Theseparameterscanbesetonaprogrammabledigitaloutput.
*****TheseparameterscanbesetonRelay2.
Pad 0...15 Generalvariables,16Bit.ThePads0...3canbesetviaanaloginputs.Thevaluesofthe
Pads0,1,4,5and6canbesetonanalogoutputs.
Bitword pad A (B) Bitmapoftheparameters Pad A (B) bit0uptoPadA (B) bit 15.Withaparameterit
ispossibletoreadorwritealltheBitsinsideaWord.
Example: PadAbit0  0
   PadAbit1  1 =2
1
=2
   PadAbit2  0
   PadAbit3  0
   PadAbit4  0
   PadAbit5  1 =2
5
 =32
   PadAbit6  1 =2
6
 =64
   PadAbit7  0
   PadAbit8  0
   PadAbit9  0
   PadAbit10  1 =2
10
  =1024
   PadAbit11  0
   PadAbit12  1 =2
12
  =4096
   PadAbit13  0
   PadAbit14  0
  PadAbit15  0
 BitwordpadA=2+32+64+1024+4096=5218
Pad A (B) bit 0...15 Bitvariables.ThesingleBitscanbereadorwritten.WiththeBitword pad A (B)itis
possibletoprocessaWord.Seetheexample.FromthePadAitispossibletoreadthe
Bits0.....7ofadigitalinput.OnadigitaloutputitispossibletowritealltheBit.
Analog
input
Analog
output
Analog
output
Analog
input
Digital
input
Digital
output
Digital
output
General PAD
Pad 0
0
Pad 1
0
Pad 2
0
Pad 3
0
Pad 4
0
Pad 5
0
Pad 6
0
Bitword pad A
0000h
Bitword pad B
0000h
Pad 7
0
Pad 8
0
Pad 9
0
Pad 10
0
Pad 11
0
Pad 12
0
Pad 13
0
Pad 14
0
Pad 15
0
INTERBUS S, PROFIBUS DP, etc.
Options (Bus Interface ....)KeypadRS 485
M- M+ AL EN n=0 Ilim
E
CANC
–
+
Figure 6.15.5.1: Bus pads
note WhensettingthePADsbittodigitalI/Othefollowingruleshavetobeaplied:
 1. AssigningPADA/BbittoaDigitalOutputwillcausethestateofthedigitaloutput(n)
comingfromPADA/Bbit(n-1)
