—————— TPD32-EV ——————
86
4.9 CIRCUIT PROTECTION
4.9.1 Fuses
Fuses of the power section
M
UVW
CD
U1 V1
C1 D1
FA
FB
M
UVW
CD
U1 V1
C1 D1
FC
Forma costruttiva A- B
Frame A- B
Forma costruttiva C - D - E
Frame C - D - E
F
DFD
Figure 4.9.1.1: Position of the super fast fuses
Forprotectionofthebridgethristorsusefastactingfuses.
ThefusesFAandFBareexternallymounted.
SizesTPD32EV-...-C,TPD32EV-...-DandTPD32EV-...-Earealreadyttedwithfast-actingmainsfuses(FC).
note!  Technicalcharacteristicsoffuses,includingsize,weight,dissipation,heat,etc.areprovidedin
therelativefusemanufacturers’catalogues(Z...=JeanMuller;FWP…,170M...=Bussmann;
A...=GouldShawmut).
