—————— Instruction manual ——————
65
Table 4.3.3: Cable section for UL approval
Device type Terminals Wire
AWG / kcmils
Terminal bolt
metric size [mm]
Tightening torque
[Nm]
TPD32-EV-.../...-20-..-A U, V, W, C, D PE 10 5 6
TPD32-EV-.../...-40-..-A U, V, W, C, D PE 8 5 6
TPD32-EV-.../...-70-..-A U, V, W, C, D PE 4 5 6
TPD32-EV-.../...-110-..-A
U, V, W C, D 1/0 terminal block 12
PE 2 terminal block 12
TPD32-EV-.../...-140-..-A
U, V, W C, D 2/0 terminal block 12
PE 2 terminal block 12
TPD32-EV-.../...-185-..-A
U, V, W 3/0 terminal block 12
C, D 4/0; kit required terminal block 12
PE 2 terminal block 12
TPD32-EV-.../...-280-..-B
U, V, W C, D 2 x 2/0 10 50
PE 2/0 8 25
TPD32-EV-.../...-350-..-B
U, V, W C, D 2 x 4/0 10 50
PE 2/0 8 25
TPD32-EV-.../...-420-..-B
U, V, W 2 x 4/0 10 50
C, D 2 x 300 10 50
PE 2/0 8 25
TPD32-EV-.../...-500-..-B
U, V, W 2 x 300; kit required 10 50
C, D 2 x 350; kit required 10 50
PE 2/0 8 25
TPD32-EV-.../...-560-..-C
TPD32-EV-.../...-700-..-C
U, V, W 4 x 4/0 10 50
C, D 4 x 250 10 50
PE 2/0 8 25
TPD32-EV-.../...-650-..-B
U, V, W 2 x 500; kit required 10 50
C, D 2 x 600; kit required 10 50
PE 2/0 8 25
TPD32-EV-.../...-770-..-C
U, V, W 4 x 1/0 10 50
C, D 4 x 2/0 10 50
PE 1 8 25
TPD32-EV-.../...-900-..-C
U, V, W 2 x 400; kit required 10 50
C, D 2 x 600; kit required 10 50
PE 1 8 25
TPD32-EV-.../...-1050-..-C
U, V, W 4 x 300; kit required 10 50
C, D 4 x 400; kit required 10 50
PE 2/0 8 25
TPD32-EV-.../...-1000-..-C
TPD32-EV-.../...-1050-..-C
U, V, W 4 x 300; kit required 10 50
C, D 4 x 4/0; kit required 10 50
PE 2/0 8 25
TPD32-EV-.../...-1000-..-C
U, V, W 4 x 300; kit required 10 50
C, D 4 x 350; kit required 10 50
PE 2/0 8 25
TPD32-EV-.../...-1300-4B-D
U, V, W 4 x 300; kit required 12 45
C, D 4 x 4/0; kit required 12 45
PE 2/0 12 45
TPD32-EV-.../...-1300-2B-D
U, V, W 4 x 250; kit required 12 45
C, D 4 x 400; kit required 12 45
PE 2/0 12 45
TPD32-EV-.../...-1400-..-D
U, V, W 4 x 350 12 45
C, D 4 x 500 12 45
PE 5 x 60 12 45
TPD32-EV-.../...-1600-..-D
U, V, W 4 x 500; kit required 12 45
C, D 5 x 500; kit required 12 45
PE 5 x 60 12 45
TPD32-EV-.../...-1900-..-D
TPD32-EV-.../...-2000-..-D
U, V, W 5 x 500; kit required 12 45
C, D 6 x 500; kit required 12 45
PE 8 x 60 12 45
TPD32-EV-.../...-2100-..-D
U, V, W 6 x 400; kit required 12 45
C, D Busbar or Flexibar 12 45
PE 8 x 60 12 45
TPD32-EV-.../...-2300-..-D
TPD32-EV-.../...-2400-..-D
U, V, W 6 x 500; kit required 12 45
C, D Busbar or Flexibar 12 45
PE 8 x 60 12 45
